Deep C® Tiger Claw

  • Volume 220 L
  • Lifting capacity 900 kg SWL
  • Hydraulically operated
  • Can be fitted with 360 degrees rotator

Request more information

Category:

Download as pdf

Description

The Deep C® Tiger Claw is a robust and versatile hydraulically operated grapper tool. The Deep C® Tiger Claw is designed to be operated by Deep C® SUV® or deployed by vessel crane. The hydraulic supply can either be provided from Deep C® SUV®, ROV or through topside supply.

Applications

  • Relocation of debris
  • Removal of boulders
  • Pipe grappling
  • Subsea lifting

Technical specifications

Volume 220 liters
SWL 900 kg
Dimensions Closed 90 mm ; Open 1310 mm
Cylinders 1
Maximum flow 50 lpm
Pressure range 200 Bar

Transport Dimensions

Length 120 cm
Width 80 cm
Height 60 cm
Weight 100 kgs

Available complementary equipment

  • Topside HPU and reel
  • Hot stab system for ROV operations
  • ROV Dirty Work Pack
  • 360° rotator
  • Chutes for over borading of down lines
  • Subsea recovery baskets
  • Bespoke solutions
